Low amp of a Das ROAD 15A powered speaker

Photos show this part as we found it on boards during repairs - not the stock you'll receive.

BC846B

Name: BC846B NPN bipolar junction transistor, general-purpose switching and amplification
SKU: BC846B
Price: 5.00 XCD
Availability: InStock

NPN bipolar junction transistor, general-purpose switching and amplification

Marking on the part: 1B

Ask About This Part

Where to buy online

Mouser DigiKey LCSC Amazon eBay AliExpress

Other stores - prices, stock and shipping are theirs.

Datasheet

Identified on 17 board photos in 7 devices

Specifications (BJT)

NPN, PNP	NPN
Max collector power dissipation	0.25 W
Max collector-base voltage \|Vcb\|	80 V
Max collector-emitter voltage \|Vce\|	65 V
Max emitter-base voltage \|Veb\|	6 V
Max collector current \|Ic\|	0.1 A
Max junction temperature	150 deg C
Transition frequency	100 MHz
Min forward current transfer ratio (hFE)	200
Package, e.g. TO220	SOT23

Found in these devices

Where we've identified this part on boards we've worked on.

Device	Board	Position on board
Behringer POWERPLAY P16-M personal monitor mixer	Main board, Panel board	T5, T3
Dbtech SIGMA S215 powered speaker	Main board	Q6, Q5, Q4
Rcf NX 985-A powered speaker	Main board
Cvr CV-218CP6 powered sub	Main board	IC8, IC9
Das ROAD 15A powered speaker	Low amp
Ld Systems ICOA 15 A BT powered speaker	Input board
Rcf SUB8003-AS powered sub	Main board	T119
