1 / 12d5 · Input board of a Jbl EON615 powered speaker
Photos show this part as we found it on boards during repairs - not the stock you'll receive.
Found in these devices
Where we've identified this part on boards we've worked on.
| Device | Board | Position on board |
|---|---|---|
| Das AERO40A line array | Digimod 1000 | D21, D20, D18, D19 |
| Jbl EON715 powered speaker | Dsp board | D9 |
| Das COMPACT-2 powered speaker | Low amp, High amp | |
| Lab Gruppen FP14000 amplifier | Pwm board | D1, D2 |
| Rcf SUB8006 powered sub | ||
| Behringer POWERPLAY P16-M personal monitor mixer | Main board | D2 |
| Jbl EON615 powered speaker | Input board | D5 |
| Yamaha DXS18XLF powered sub | Power amp board |
