1 / 12Preamp board of a Presonus STUDIOLIVE 16.4.2 mixer
Photos show this part as we found it on boards during repairs - not the stock you'll receive.
Found in these devices
Where we've identified this part on boards we've worked on.
| Device | Board | Position on board |
|---|---|---|
| Presonus STUDIOLIVE 16.4.2 mixer | Preamp board, Dsp board | |
| Das COMPACT-2 powered speaker | Low amp, High amp | IC1, IC2 |
| Jbl EON615 powered speaker | Input board | U5, U6, U7 |
| Jbl EON618S powered sub | Input board | U5 |
| Das AERO40A line array | Dsp board | U6, U4 |
| Rcf SUB8003-AS powered sub | Main board | IC200 |
| Tvi C-210II powered speaker | High amp | IC4, IC2 |
| Rcf SUB8006 powered sub | IC100 |
From our repair bench
3
repairs involving this part
1
times replaced
1
found faulty
1
checked and OK
In 0 of 1 repairs where it was replaced, the device was fixed.
Failed or replaced in: Das AERO40A (1), Jbl EON615 (1)
Totals across every repair logged on Circuit Fixers.
